Printed circuit board 9y 9W SMD(120 pieces)1000x8mm tape CCT
- Light colour 3000/4000/6000 Kelvin
- Luminous flux 1070 lumen
- 9 watts
- Length 1000 mm
- Width 8 mm
Article number:
LED 9y 9W SMD(120pcs)1000x8mm Band CCT
Availability:
Not available
Energy efficiency:
Product number: 199.0009-25
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 9y 9W SMD(120 pieces)1000x8mm tape CCT
| Length: | 1000 mm |
|---|---|
| Width: | 8 mm |
| Height: | 1 mm |
| Dimmable: | Yes |
| Light Temperature: | 3000/4000/6000 Kelvin (warm white to cool white) |
| Wattage: | 9 W |
| Voltage: | 24 V |
| Number of LEDS: | 120 |
| Luminous Flux: | 1070 lm |
| Colour Rendering Index: | 80 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 1,00 |
| R9 Colour rendering index [0-100]: | 6 |
| Weighted Energy Consumption: | 9 kw/1000h |
