Printed circuit board 9,6a 9,6W SMD(48 pieces) 60x80mm 3000K 1000Lm
- Light colour 3000 Kelvin
- Luminous flux 1000 lumen
- 9,6 Watt
- Length 80 mm, width 60 mm
Article number:
LED 9,6a 9,6W SMD(48pcs.) 60x80mm 3000K
Availability:
Now
Energy efficiency:
Product number: 199.0009-020
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 9,6a 9,6W SMD(48 pieces) 60x80mm 3000K 1000Lm
| Length: | 80 mm |
|---|---|
| Width: | 60 mm |
| Height: | 1 mm |
| Dimmable: | Yes |
| Dimmable with typ of dimmer: | LED dimmer, Trailing edge dimmer |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 9,6 W |
| Number of LEDS: | 48 |
| Luminous Flux: | 1000 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 40 |
| Net Weight: | 0,1 kg |
