Printed circuit board 7r 7W SMD(35 pieces)220x18mm 3000K 700Lm
- Light colour 3000 Kelvin
- Luminous flux 700 lumen
- 7 watt
- Length 220 mm, width 18 mm
Product number: 199.0007-18
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 7r 7W SMD(35 pieces)220x18mm 3000K 700Lm
| Length: | 220 mm |
|---|---|
| Width: | 18 mm |
| Height: | 1 mm |
| Dimmable: | Yes |
| Dimmable with typ of dimmer: | LED dimmer, Trailing edge dimmer |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 7 W |
| Number of LEDS: | 35 |
| Luminous Flux: | 700 lm |
| Colour Rendering Index: | 90 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 60 |
| Net Weight: | 0,1 kg |
