Printed circuit board 5ab 5W COB 17x14mm(Ø10mm) 3000K 300Lm
- Light colour 3000 Kelvin
- Luminous flux 300 lumen
- 5 watt
- Length 17 mm
- Width 14 mm
Product number: 199.0005-010
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 5ab 5W COB 17x14mm(Ø10mm) 3000K 300Lm
| Length: | 17 mm |
|---|---|
| Width: | 14 mm |
| Height: | 2 mm |
| Diameter: | 10 mm |
| Dimmable: | NO |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 5 W |
| Luminous Flux: | 300 lm |
| Colour Rendering Index: | 80 |
| Peak muninous intensity: | 780 cd |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 1,00 |
| R9 Colour rendering index [0-100]: | 10 |
