Printed circuit board 25f 25W SMD(130 pieces) CCT(3000K/4000K/6000K)
- Light colour 3000/4000/6000 Kelvin
- Luminous flux 3150 lumen
- 25 watts
- Ø 134 mm
Product number: 199.0025-06
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 25f 25W SMD(130 pieces) CCT(3000K/4000K/6000K)
| Height: | 1 mm |
|---|---|
| Diameter: | 134 mm |
| Dimmable: | Yes |
| Light Temperature: | 3000/4000/6000 Kelvin (warm white to cool white) |
| Wattage: | 25 W |
| Number of LEDS: | 130 |
| Luminous Flux: | 3150 lm |
| Colour Rendering Index: | 80 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 1 |
| Weighted Energy Consumption: | 21 kw/1000h |
| Net Weight: | 0,10 kg |
