Printed circuit board 20n 20W SMD(208 pieces) 275x550mm 1/2 pitch circle 3000K 4000Lm
- Light colour 3000 Kelvin
- Luminous flux 4000 lumen
- 20 watts
- Length 275 mm
- Width 550 mm
Article number:
LED 20n 20WSMD(208pcs) 550mm 1/2 (3000K)
Availability:
Now
Energy efficiency:
Product number: 199.0020-14
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 20n 20W SMD(208 pieces) 275x550mm 1/2 pitch circle 3000K 4000Lm
| Length: | 275 mm |
|---|---|
| Width: | 550 mm |
| Height: | 1 mm |
| Dimmable: | Yes |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 20 W |
| Number of LEDS: | 208 |
| Luminous Flux: | 4000 lm |
| Colour Rendering Index: | 80 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 1,00 |
| R9 Colour rendering index [0-100]: | 12 |
