Printed circuit board 17d 17W SMD(17 pieces) 480x20mm 3000K 1815Lm
- Light colour 3000 Kelvin
- Luminous flux 1815 lumen
- 17 watt
- Length 480 mm
- Width 20 mm
Article number:
LED 17d 17W SMD(17pcs) 480x20mm 3000K
Availability:
Now
Energy efficiency:
Product number: 199.0017-04
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 17d 17W SMD(17 pieces) 480x20mm 3000K 1815Lm
| Length: | 480 mm |
|---|---|
| Width: | 20 mm |
| Height: | 2 mm |
| Dimmable: | Yes |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 17 W |
| Number of LEDS: | 17 |
| Luminous Flux: | 1815 lm |
| Colour Rendering Index: | 83 |
| Peak muninous intensity: | 990 cd |
| Stroboscopic effect metric [SVM]: | 0,4 |
| Flicker metric [PstLM]: | 0,9 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 1,00 |
| R9 Colour rendering index [0-100]: | 7 |
