Printed circuit board 12d 12W SMD(60 pieces) 419x8mm 1/3 pitch circle 3000k 1400Lm
- Light colour 3000 Kelvin
- Luminous flux 1400 lumen
- 12 watts
- Length 419 mm
- Width 8 mm
Article number:
LED 12d 12W SMD(60pcs)D400x7,5mm 1/3 Tei
Availability:
Now
Energy efficiency:
Product number: 199.0012-04
- Fast europe-wide delivery
- Illuminants and spare parts warranty
- High quality
Downloads
Datenblatt DE - Datasheet EN
(0.5MB)
Description
Printed circuit board 12d 12W SMD(60 pieces) 419x8mm 1/3 pitch circle 3000k 1400Lm
| Length: | 419 mm |
|---|---|
| Width: | 8 mm |
| Height: | 1 mm |
| Dimmable: | Yes |
| Light Temperature: | 3000 Kelvin (warm white) |
| Wattage: | 12 W |
| Number of LEDS: | 60 |
| Luminous Flux: | 1400 lm |
| Colour Rendering Index: | 80 |
| Mains or non-mains [MS or NMS]: | Non Mains |
| Non-directional or directional [NDL or DL]: | non-directional light source |
| Lumen maintaince factor [0-1]: | 0,96 |
| Survival factor [0-1]: | 0,90 |
| R9 Colour rendering index [0-100]: | 0 |
